D1524R High-speed Refrigerated Micro Centrifuge

D1524R High-speed Refrigerated Micro Centrifuge


product Description

High Speed Desktop Refrigerated Micro Centrifuge D1524R

Key Features of D1524R Centrifuge

• Centrifuge chamber door with automatic adsorption door lock design, can be closed with a single finger.
• Precooling, the compressor will automatically start cooling as long as the set temperature is lower than the ambient temperature.
• Sound indicator to prompt that the upper cover is closed to maintain the temperature inside the chamber, after centrifugation.
• Advanced R290 fluorine free refrigerant, low carbon and environmental protection.
• Maximum rotation speed can be achieved even at 4℃.
• Up to 9 program storage capacity according to experimental needs.
• Biosafety rotor, three-layer seal for biosafety
• High-strength aluminum alloy, three layered biosafety to withstand numerous high temperature and high pressure sterilizations.
• Five rotors with 0.2mL, 0.5mL, 1.5mL, 2mL and 5mL centrifuge tubes/ PCR tubes capacity.
• An external condensation tank prevents condensate within the centrifuge chamber.

Speecifications of high-speed micro centrifuge

SpecificationsD1524R
Max. Speed15,000rpm (200-15,000rpm) in 100rpm increments.
Max. RCF21,380×g, step: 10×g
Capacity1.5/2mL×24, 0.5mL×36, PCR8×4, 5mL×12, 5mL×18.
Temperature setting -20℃- 40℃
Timing30s-99 min; HOLD (continuous running)
Motor TypeDC brushless motor
Safety PerformanceDual door lock, over-speed detection, over-temperature detection with Internal diagnosis system.
Power RequirementsSingle phase, 200-240V, 50Hz, 500W
Dimensions(mm)332(Width) × 553(depth) × 283(height)
Weight30kg
Acceleration and deceleration time25s↑25s↓
Noise≤56dB
Other functionsRotation speed/RCF switchover, inching operation, running process indicator, sound alert. Acceleration/ deceleration in 9 steps, program storage capacity.

Order Info

Cat. No.P/NDescriptionsPower supply
9013111121D1524RHigh Speed Refrigerated Micro-CentrifugeUS plug, 110-120V/50Hz/60Hz
Cn plug, 220-240V/50Hz/60Hz
Euro plug , 220-240V/50Hz/60Hz
UK plug, 220-240V/50Hz/60Hz
